Eddie Gonzales Jr. – MessageToEagle.com – There is a new evidence for the possible existence of liquid water beneath the south polar ice cap of Mars, researchers say. An international team of researchers led by the University of Cambridge, used spacecraft laser-altimeter measurements of the shape of the upper surface of the ice cap to identify subtle patterns in its height.
The left-hand panel shows the surface topography of Mars’s south pole, with the outline of the south polar cap in black. The light blue line shows the area used in the modelling experiments, and the green square shows the region containing the inferred subglacial water. The ice in the region is around 1500 m thick. The right-hand panel shows the surface undulation identified by the Cambridge-led research team. It is visible as the red area, which is elevated by 5-8 m above the regional topography, with a smaller depression (2-4 m below the regional topography) upstream (towards the top right of the image). The black outline shows the area of water as inferred by the orbiting radar. Credit: University of Cambridge
They then showed that these patterns match computer model predictions for how a body of water beneath the ice cap would affect the surface.
Their results agree with earlier ice-penetrating radar measurements that were originally interpreted to show a potential area of liquid water beneath the ice. There has been debate over the liquid water interpretation from the radar data alone, with some studies suggesting the radar signal is not due to liquid water.
The results, reported in the journal Nature Astronomy, provide the first independent line of evidence, using data other than radar, that there is liquid water beneath Mars’ south polar ice cap.
“The combination of the new topographic evidence, our computer model results, and the radar data make it much more likely that at least one area of subglacial liquid water exists on Mars today, and that Mars must still be geothermally active in order to keep the water beneath the ice cap liquid,” said Professor Neil Arnold from Cambridge’s Scott Polar Research Institute, who led the research.
Like Earth, Mars has thick water ice caps at both poles, roughly equivalent in combined volume to the Greenland Ice Sheet. Unlike Earth’s ice sheets however, which are underlain by water-filled channels and even large subglacial lakes, the polar ice caps on Mars have until recently been thought to be frozen solid all the way to their beds due to the cold Martian climate.
Planum Australe – Mars. Image credit – NASA
In 2018, evidence from the European Space Agency’s Mars Express satellite challenged this assumption. The satellite has an ice-penetrating radar called MARSIS, which can see through Mars’ southern ice cap. It revealed an area at the base of the ice that strongly reflected the radar signal, which was interpreted as an area of liquid water beneath the ice cap.
However, subsequent studies suggested that other types of dry materials, which exist elsewhere on Mars, could produce similar patterns of reflectance if they exist beneath the ice cap. Given the cold climate conditions, liquid water beneath the ice cap would require an additional heat source, such as geothermal heat from within the planet, at levels above those expected for present-day Mars. This left confirmation of the existence of this lake awaiting another, independent line of evidence.
On Earth, subglacial lakes affect the shape of the overlying ice sheet—its surface topography. The water in subglacial lakes lowers friction between the ice sheet and its bed, affecting the velocity of ice flow under gravity. This in turn affects the shape of the ice sheet surface above the lake, often creating a depression in the ice surface followed by a raised area further down-flow.
The team—which also included researchers from the University of Sheffield, the University of Nantes, University College, Dublin, and the Open University—used a range of techniques to examine data from NASA’s Mars Global Surveyor satellite of the surface topography of the part of Mars’ south polar ice cap where the radar signal was identified.
Their analysis revealed a 10-15 kilometer-long surface undulation comprising a depression and a corresponding raised area, both of which deviate from the surrounding ice surface by several meters. This is similar in scale to undulations over subglacial lakes here on Earth.
The team then tested whether the observed undulation on the surface of the ice could be explained by liquid water at the bed. They ran computer model simulations of ice flow, adapted to specific conditions on Mars. They then inserted a patch of reduced bed friction in the simulated ice sheet bed where water, if present, would allow the ice to slide and speed up. They also varied the amount of geothermal heat coming from inside the planet.
These experiments generated undulations on the simulated ice surface that were similar in size and shape to those the team observed on the real ice cap surface.
The similarity between the model-produced topographic undulation and the actual spacecraft observations, together with the earlier ice-penetrating radar evidence suggest that there is an accumulation of liquid water beneath Mars’ south polar ice cap, and that magmatic activity occurred relatively recently in the subsurface of Mars to enable the enhanced geothermal heating needed to keep the water in a liquid state.
“The quality of data coming back from Mars, from orbital satellites as well as from the landers, is such that we can use it answer really difficult questions about conditions on, and even under the planet’s surface, using the same techniques we also use on Earth,” said Arnold. “It’s exciting to use these techniques to find out things about planets other than our own.”
Written by Eddie Gonzales Jr. – MessageToEagle.com Staff
